Migrating from Redshift to Snowflake

Redshift is awesome, but we needed to move forward. It was a huge challenge and here's how we managed to do it.

The backstory

I joined Receipt Bank as a software developer about three years ago. My last onboarding task gave me a good overview of the data flow, and I was offered to join the data engineering team shortly after I finished my onboarding. I haven't had prior experience in this area, but I was keen to learn more, so I happily accepted.

Redshift

Like many other companies, we use every AWS service we can, so it shouldn't surprise you that we used Redshift as a warehousing solution. Redshift is actually awesome. It's an easy and cheap way to start when you need a data warehouse, not to mention it's based on the good old PostgreSQL.

There are two types of Redshift cluster nodes - compute-optimized with small SSDs, and storage optimized with large HDDs. We started with 10 dc2.large (dense compute) machines which served us well for a while.

The project was adopted rather well, and our data volumes were increasing fairly quickly. We had to add new nodes every few months, and two years later, we hit the limit of 32 compute machines. Unfortunately, we can't mix compute and storage nodes. Our only option was to switch to the larger disks. Of course, we'd seen that coming and started preparing upfront. We secured some time by migrating to a cluster with a few ds2.xlarge workers and caching the most used queries with dbt transformations. We had the memory and CPU to run our reports at a reasonable speed, and the space to switch to Snowflake.

Snowflake

You can often hear people talk about it as a warehouse built for the cloud, but what does that mean? Snowflake works on (at least) the three major providers - AWS, GCP and Azure and it's up to you to choose the provider and availability zone for your setup. Just keep in mind that Snowflake is a managed service, so you don't have access to the underlying resources, and the choice could affect the traffic costs for your cloud provider.

Snowflake is not an AI-Blockchain-NoSQL-Graph database. In fact, on the first look it looks like a traditional PostgreSQL, but don't let the familiar syntax and intuitive UI lie to you. Snowflake is a completely separate warehouse built from the ground up. Snowflake has separated its computing from the storage. It's like having two separate computers which you can access through the local network. If you need more storage for your multimedia, you upgrade one, and if you need more power for your games, you upgrade the other.

I won't talk too much about Snowflake, as there are tons of resources out there, but I'd say it's pretty damn good!

Migration

ETL

Our first step was to migrate our ETL, and as with most of our data infrastructure, it was highly coupled to AWS. It cost us some time for planning and quite some time for execution, but once we ran it, it worked like a charm. Here's what we've done.

Defined critical metrics

We started by defining the most important criteria for success. We created a Looker dashboard with looks for the average query runtime and the percentage of fast queries and a list of slow queries. The results in this dashboard were one of the top criteria we'd use for our buy/no-buy decision.

Created a Snowflake adapter for the ETL

Our PySpark ETL was working for years, and we were planning to continue supporting Redshift for a few months after the official migration. The plan was to run the ETL both for Redshift and Snowflake.

We started by creating a Snowflake adapter with the same public API we had for Redshift and wrapped all of this with a Strategy class.

Leaving pipelines like that would create various problems for us. We wanted to feed Redshift and Snowflake independently, so if the load fails for one warehouse it still could pass for the other. Of course, we didn't want to run the extractions and transformations twice and pay twice for the same task.

We end up splitting every pipeline into three separate jobs. One job running just the ET and producing CSV files in S3, one loading CSVs into Redshift and one loading the same data into Snowflake.

Decoupling the pipelines took us some time but made maintenance much easier. Not to mention shutting down Redshift pipelines in a later stage.

Write migration scripts

That, in my opinion, was one of the most challenging technical aspects of the project. We created a couple of scripts for that purpose. The idea was to make something that could crawl the database. Then add new data in Redshift while working on the migration without hardcoding schemas, tables and views.

With the first script, we were able to copy the structure of the Redshift database into Snowflake. It basically listed all schemas, tables and views in them. It also generated CREATE queries. The last job of this script was to set proper permissions for every asset.

With the second script, we could copy the data from one warehouse to the other. It was as simple as dumping all the data in CSV files in S3 and then copying this data into Snowflake.

It doesn't look like a hard task, but a lot is going on here. First of all, we need to make sure we don't miss any table, view or whatever we want to recreate into Snowflake. We also should keep in mind, that Redshift and Snowflake have slightly different syntax, and the DDL doesn't match. That means we can't just get the one provided by Redshift, and we have to generate it for ourselves.

Unloading and copying data normally is a trivial task. The complication in our case came from the way we use our warehouses. We have people working in (almost) all timezones who need almost live data, and every hour without this data makes them blind. That means we had to find a good balance between quick parallel dumps and enough power to run SELECT queries.

Run the migration

So we prepared and tested everything. It was time to run the migration.

One day (or rather one night) we stopped the ETL, including our internal Spark pipelines as well the syncs from Segment and Fivetran. Then, we started our migration scripts, and a few hours later, when everything finished (surprisingly without any errors) we started the ETL with Snowflake support.

Epilogue

So, almost one year after the migration, I'd say it was a fairly successful project. We did well and secured virtually unlimited storage and computing power. We moved our transformations entirely to dbt and increased the data volumes tens of times since then.

It's important to say we pay much more for Snowflake than what we have been paying for Redshift, but it works well for our use case.

What are your thoughts?
